Description
| Standard | DIN,3A,SMS,RJT,ISO,IDF,DS,Macon,GB |
| Size | 1”-6” DN10-DN200 17.2-168.3 |
| Steel material | 304,304L,316,316L(Forging) |
| Seal material | NBR,Silicone,EPDM,EFPM,PTFE |
| Surface qualities | 1.Ra≤1.6µm |
| 2.Ra≤0.87µm | |
| 3.Ra≤0.4µm(Polished) |
0%
|
Size |
A | B | C | M | H |
|
10 |
18 | 12.2 | 38 | Rd28X1/8” | 34 |
|
15 |
24 | 18.2 | 44 | Rd34X1/8” | 34 |
|
20 |
30 | 22.2 | 54 | Rd44X1/6” | 36 |
|
25 |
35 | 28.2 | 63 | Rd52X1/6” | 45 |
| 32 | 41 | 34.2 | 70 | Rd58X1/6” |
51 |
| 40 | 48 | 40.2 | 78 | Rd65X1/6” |
53 |
| 50 | 61 | 52.2 | 92 | Rd78X1/6” |
57 |
| 65 | 79 | 70.4 | 112 | Rd95X1/6” |
65 |
| 80 | 93 | 85.4 | 119 | Rd110X1/4” |
75 |
|
100 |
114 | 104.3 | 148 | Rd130X1/4” | 89 |
|
125 |
/ | / | / | / |
/ |
| 150 | / | / | / | / |
/ |
| Standard | DIN,3A,SMS,RJT,ISO,IDF,DS,Macon,GB |
| Size | 1”-6” DN10-DN200 17.2-168.3 |
| Steel material | 304,304L,316,316L(Forging) |
| Seal material | NBR,Silicone,EPDM,EFPM,PTFE |
| Surface qualities | 1.Ra≤1.6µm |
| 2.Ra≤0.87µm | |
| 3.Ra≤0.4µm(Polished) |
